SCM-Sergiani GS

Guaranteed high surface and gluring quality of the product being pressed.

SKU: SCM-SGS Category: Brand:

Description

The SCM-Sergiani GS is a versatile hot press designed for high-quality gluing and surface finishing of veneered panels, hollow-core doors, and multi-layered panels. Its robust structure, engineered with a high safety coefficient, ensures maximum resistance and rigidity throughout all processing phases. Chromed, rectified steel hydraulic cylinders with high-resistance gaskets guarantee long service life and a perfect seal. The press features a Siemens colour touchscreen control panel, allowing automatic calculation of hydraulic pressure, heating system management, full diagnostics, and the ability to program and save working parameters. Manual loading and unloading, combined with precise mechanical machining, provide exceptional versatility and consistent, professional results.

gs 4 /20 4 cylinders / 20 ton. - platens 2500 x 1300 mm
gs 4 / 60 4 cylinders / 60 ton. - platens 2500x1300 mm
gs 6 / 30 6 cylinders / 30 ton. - platens 3000x1300 mm
gs 6 / 90 6 cylinders / 90 ton. - platens 2500 x 1300 mm
gs 6 / 120 6 cylinders / 120 ton. - platens 2500 x 1300 mm
gs 6 / 120 6 cylinders / 120 ton. - platens 2500 x 1600 mm
gs 6 / 70 6 cylinders / 70 ton. - platens 3000 x 1300 mm
gs 6 / 90 6 cylinders / 90 ton. - platens 3000 x 1300 mm
gs 6 / 120 6 cylinders / 120 ton. - platens 3000 x 1300 mm
gs 6 / 90 6 cylinders / 90 ton. - platens 3100 x 1300 mm
gs 6 / 120 6 cylinders / 120 ton. - platens 3100 x 1300 mm
gs 6 / 120 6 cylinders / 120 ton. - platens 3100 x 1600 mm
gs 6 / 90 6 cylinders / 90 ton. - platens 3500 x 1300 mm
gs 6 / 120 6 cylinders / 120 ton. - platens 3500 x 1300 mm
gs 8 / 160 8 cylinders / 160 ton. - platens 3000 x 1300 mm
gs 8 / 160 8 cylinders / 160 ton. - platens 3100 x 1300 mm
gs 8/ 160 8 cylinders / 160 ton. - platens 3100 x 1600 mm
gs 8/ 110 8 cylinders / 110 ton. - platens 3500 x 1300 mm
gs 8/ 160 8 cylinders / 160 ton. - platens 3500 x 1300 mm
gs 8/ 160 8 cylinders / 160 ton. - platens 3800 x 1600 mm
gs 10/ 200 10 cylinders / 200 ton. - platens 3500 x 1300 mm
gs 10/ 200 10 cylinders / 200 ton. - platens 3800 x 1600 mm
Type of platens PA Assembled - PM Solid - PE Electric
Heating BA Electrical water boiler - BO Electrical oil boiler - PE Electrical platens
