SCM Cut C 50

The entry level solution for small batch production or order by order.

SKU: SCM-CC50 Category: Brand:

Description

The SCM Cut C 50 is a functional, compact packaging solution designed to deliver exceptional flexibility in custom box production. Equipped with seven longitudinal cutting and creasing groups plus a transverse unit, it allows operators to create a wide range of box sizes and types, either by selecting a format directly from the interface or by scanning a barcode that sends product dimensions to the machine. The Cut C 50 can be fitted with a standard two-fanfold unwinding structure, or optionally with a four-fanfold system featuring an automatic selector for even greater versatility. By producing packaging that matches the exact dimensions of each product, the machine minimizes the need for additional filling materials and reduces associated labor time, while also eliminating the need to store and handle numerous box formats — optimizing both space and workflow in any production environment.

Max. usable carton width mm 2500
Productivity box/min 2
Productivity batch 1 box/day 0 - 500
Productivity batches box/day 0 - 750
Cardboard feed speed m/min 36
Single carton feed fanfold
Longitudinal units no. 7
Creasing normal
Cardboard thickness mm 2 to 5
Minimum open box length produced mm 420
